Sigfox
* ATO16=XX with XX the transmission period in minutes in hexadecimal.
Example, for a period of 10 minutes: ATO16 = 0A
In alarm mode, a frame can be reassembled periodically to return the temperature if a T ° C sensor is integrated into
the product, and to obtain Downlink windows.
ATO16 = 0A is recommended for counting mode (one frame every 10 minutes)
ATO16 = 3C is recommended in alarm mode, to have a Downlink window every 60min
Optional: Temperature sensor
The last 2 bytes of standard frames correspond to a temperature value measured by a sensor on board the PIR. From
this we can roughly estimate the temperature of a room using the following formula
With Vt = value of byte 7 and 8 of standard frames
and Vdd = battery voltage raised in the life frames.
This sensor is not systematically wired to the PIRs, it is optional.
