Technical features
a. Consumption
Product
Standby
Reception
Emission
ACW-PIR360-I
LoRa
15µA
29mA
53mA
Sigfox
13µA
17mA
24mA
ACW-PIR90-I
LoRa
15µA
28mA
55mA
Sigfox
11µA
17,5mA
25mA
ACW-PIR180-O
LoRa
19µA
29mA
57mA
Sigfox
13µA
16mA
26mA
ACW-PIR90-O
LoRa
13µA
29mA
55mA
Sigfox
10µA
16mA
23mA
ACW-ILB30
LoRa
400µA
30mA
60mA
Sigfox
400µA
18mA
25mA
ACW-ILB100
LoRa
400µA
30mA
60mA
Sigfox
400µA
17mA
21mA
b. Power Supply
The indoor (I) and outdoor (O) PIR ranges all use the same lithium battery model: 3v6 format 2 / 3AA.
CAUTION: Do not use other models, otherwise the product may be damaged. Also observe the polarity.
Product
Batteries
Attachment
ACW-PIR360-I
ER17335 3.6V 2/3AA
Support interne
ACW-PIR90-I
ER17335 3.6V 2/3AA
Support interne
ACW-PIR180-O
Pack 2xPiles ER17505H 3,6V
Sur bornier, interne
ACW-PIR90-O
Pack 2xPiles ER17505H 3,6V
Sur bornier, interne
ACW-ILB30
LSH20 SAFT 3,6V
Support interne
ACW-ILB100
LSH20 SAFT 3,6V
Support interne
