STEP 8
STEP 9
Page 6 of 8
Push the door closed and lock both sides as shown below.
Attach back panel (06) to cabinet assembly as shown below. Using
wood screws (D), tighten with Phillips head screwdriver (customer supplied ).
Adult assembly
Wood screw
D
Phillips head
screwdriver
Customer supplied
06
Adult assembly
Lock
NANTUCKET MURPHY BED
D
