2 General description
2.1 General description
Introduction
The air dryers described in this book are heatless adsorption dryers, built to remove moisture
from compressed air for industrial purposes.
The standard version is intended to reach a pressure dew point of -40 ˚C (-40 ˚F). There is also a
version available for a pressure dew point of -70˚C (-94 ˚F).
All units are designed for indoor use, and altitude up to 2000 m.
CD 25+ up to CD 145+, general view
Main parts
An overview of the main parts of the dryer is given in below figures:
Instruction book
API093050 9
