Reference Explanation
(c) Connection for remote control (X3): to NO contact of compressor
(d) Supply connection for 115 V and 230 V
(f) Time setting solenoid valves
(g) Connection PDP sensor
Reference Designation Reference Designation
E1 Controller card E2 LED/Display card
PDP Pressure Dew Point sensor
(optional)
X9 Supply connections
K01 Alarm relay K02 Warning relay
K03 Solenoid relay, left tower K04 Solenoid relay, right tower
Y1-(Y3)-(Y5) Solenoid valve(s) left tower Y2-(Y4)-(Y6) Solenoid valve(s) right tower
X1 Input PDP X2 Input On/Off contact
X3 Input Freeze contact S1 On/Off switch
X4 Input Ext 1 contact X5 Input Ext 2 contact
X8 CAN-Bus X11 Output alarm relay
X12 Output warning relay
X13 Output solenoid (left tower) X15 Output solenoid (right tower)
Instruction book
16 API093050
