Instruction Book
107 9829 2115 69
Design data CD 400 to CD 1600
Correction factors for inlet flow CD 350+ to CD 1400+
Tin let Working pressure (Barg)
(°F) 4.5 5 6 7 8 9 10
90
0.75 0.87 0.94 1.00 1.06 1.12 1.17
95
0.72 0.84 0.92 1.00 1.06 1.12 1.17
100
0.69 0.81 0.88 1.00 1.06 1.12 1.17
105
0.63 0.74 0.80 0.91 1.02 1.12 1.17
110
0.57 0.66 0.72 0.82 0.92 1.03 1.13
115
0.50 0.58 0.63 0.72 0.81 0.90 0.99
120
0.44 0.52 0.56 0.64 0.72 0.80 0.88
Specifications Unit CD400 CD480 CD575 CD800 CD950 CD1200 CD1450 CD1600
Desiccant type
-40
o
F variant
Activated Alumina
-40
o
F variant kg 232 281 330 462 562 726 825 924
-40
o
F variant lb 510 618 727 1018 1237 1600 1817 2035
Inlet and outlet
connection
150#
ANSI
flange
3" 3" 3" 4" 4" 4" 6" 6"
Recommended filter
DD/PD
PDp
390 520 520 780 1050 1050 1400 1400
Dimensions
-Height in 103.00 103.00 95.00 98.50 98.50 120.50 132.00 132.00
-Width in 76.26 76.26 82.41 97.03 97.03 96.47 104.00 104.00
-Depth in 41.13 41.13 41.13 48.13 48.13 48.13 63.75 63.75
Net mass with desiccant
-40
o
F variant kg 950 1030 1310 1940 2120 2600 3445 3700
-40
o
F variant lb 2093 2269 2885 4273 4670 5727 7588 8150
