Atlas Copco DD User Manual

2904 0108 04 77
DD - DDP - PD - QD : 44 - 60
Notes
1. Included in the element kit.
2. Optional.
3. Not on the QD filters.
4. Only on DD and PD filters.
5. Only on DDp and QD filters.
6. 230V 50/60Hz not on DDp and QD filters.
7. 115V 50/60Hz not on DDp and QD filters.
8. 24V 50/60Hz not on DDp and QD filters.
8
20
10
22
21
9
25
6
4
2
12
7
26
1
5
3
24
6
23
11
28
27
DD - DDp - PD - QD : 44 DD - DDp - PD - QD : 60
Ref. Part Number Note Qty Ref. Part Number Note Qty Designation
20 8092 2429 76
2
20 8092 2429 76
2
Wall mounting kit
21 8092 2430 24
2
21 8092 2430 24
2
Serial connection kit
22 • 0663 2101 97 1 22 • 0663 2101 97 1 O-ring, 38x2
23 2901 0562 00 23 2901 0562 00 Sight glass kit
24 2901 0563 00
4
24 2901 0563 00
4
Automatic drain valve kit
25 2901 0611 00
5
25 2901 0611 00
5
Manual drain valve kit
26 1617 7082 01
2
26 1617 7082 01
2
Male coupling, G 1/8”
26 1617 7082 02
2
26 1617 7082 02
2
Female coupling, G 1/8”
26 1617 7082 03
2
26 1617 7082 03
2
Hose connection
27 8055 2600 64
2/3
1 27 8055 2600 64
2/3
1 Dual pressure transmitter
28 8055 2600 31
2/6
1 28 8055 2600 31
2/6
1 EWD Connection
28 8055 2600 49
2/7
1 28 8055 2600 49
2/7
1 EWD Connection
28 8055 2600 56
2/8
1 28 8055 2600 56
2/8
1 EWD Connection
A080-070401-010
Vendor Manual Atlas Copco A090-070423-004 PD & DD Filters Instruction Manual
Q-Pulse Id VM260
Active 09/09/2013
Page 79 of 90
