Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
5x11.7 / Service kit 4216 0234 90Spacert2-4
Ø 5 mm / Service kit 4216 0230 90Ball20517 1157 005
Gear Case1-6
2.6x5 / Service kit 4216 0232 90Screw3-7
4x5.5 / Service kit 4216 0230 90Roller2-8
Plate1-9
Shaft1-10
2x13.8 / Service kit 4216 0234 90Pin1-11
Gear rim1-12
Planetary shaft1-13
Gear wheel4-14
Planetary shaft1-15
Gear wheel4-16
Sun wheel1-17
Cup Ring1-18
Handle
1
1
2
2
3
4
5
6
6
7
8
9
10
11
12
= Included in Service Kit
2010710
Remark / Included in Service kitDescriptionQtyOrdering No.Ref. No.
Casing14216 0109 001
2.6x6 / Service kit 4216 0232 90Screw2-2
3.5x12 / Service kit 4216 0232 90Screw1-3
Casing accessories14216 0168 904(5-12)
Switch1-5
Plunge2-6
4.1x9 / Service kit 4216 0231 90Spring1-7
4.85x14 / Service kit 4216 0231 90Spring1-8
Lever1-9
2x20.8 / Service kit 4216 0234 90Pin1-10
Magnet box1-11
Suspension yoke14216 0079 0012
© Atlas Copco Industrial Technique AB - 9836 8184 00
72
EBL12ENSpare part list
