Product information EN ETV ST101-270-20
6
© Atlas Copco Industrial Technique AB - 9839 1678 01
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional drawings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Overview
The Tensor system
The Tensor system consists of a range of tightening tools powered by brushless electric motors and differ-
ent drive units.
Motors are available in different sizes. All tools are protected from overheating of the motor. Electrical pro-
tection system is based on an earth fault circuit brake, Earth Fault Protector (EFP). The EFP senses small
current leakage (>30mA) and if leakage occurs, the drive is switched off (30ms). Changing, interfering or
tampering with the protection system voids all warranty and obligations from Atlas Copco. Trouble-shoot-
ing and re-start of the system may only be carried out by an authorized person. Check the function of the
EFP on a regular basis by pressing the trip-button. The EFP should switch off accordingly.
Technical data
Ordering No 8433208123
Model ETV ST101-270-20
Model type Angle
Distance center to side 32.9 mm
Speed 380 r/min
Length 672 mm
Torque range 65–270 Nm
Torque range 48–199 ft lb
Square drive 3/4 in
Weight 7.3 kg
Weight 16.1 lb
Height 62 mm
Motor power 1500 W
Motor voltage 200 V
Motor voltage type 3 a.c.
Service overview
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
