Instructions
1. Provide an isolating switch.
For the correct location of the isolating switch, see Installation proposal.
2. Check that the cables and wires inside the electric cabinet are clamped tight to their terminals.
3. Check the fuses and the setting of the upstream overload relay.
4. Check that the supply voltage is the same as the value indicated on the machine data plate.
5. Check that the electrical installation corresponds to local codes. The dryer must be earthed and
protected against short circuits using an automatic cut-out device with a differential device.
6. Connect the earth conductor (PE). For location of the electrical cable outlet, see Dimension
drawings.
7. Connect the power supply cables to their terminals.
3.3 Installation proposal
Moving
Danger:
Use a suitable tool (e.g., pallet carrier, fork lift truck) to move the dryer.
Do not use metal cables for lifting.
Move the dryer gently.
Danger:
Please keep environmental conditions stable (temperature and humidity) in order to avoid
refrigerant compressor/fan overload and/or reduction of dryer performance. Similar failures
shall affect warranty reimbursements.
Please ensure the appropriate composition of the air within the machine room: - clean with
no damaging contaminants (e.g., dust, fibers, fine sand) - free of explosive or chemically
unstable gases or vapors - free of acid/alkaline forming substances, particularly ammonia,
chlorine or hydrogen sulfide. Similar failures shall affect warranty reimbursements.
Please remember that we do not recommend the application of duct to extract air in
presence of axial fans.
All refrigerant dryers shall be equipped with proper pre-filter at closest position to dryer air
inlet (to be replaced according to service plan: once per year or even before in case of
particular high humidity ambient conditions).
Instruction book
