Atlas Copco F6 - Correction Factor

Unit F200 F230 F285 F335 F400
Air connections (Male) G2.5" G2.5" G2.5" G2.5" G2.5"
Condensate
drain (rubber
pipe)
mm 8 8 8 8 8
9.3 Correction factor
Correction factor K = A*B*C
(A) Ambient temperature (°C) Correction factor
25 1
30 0.91
35 0.81
40 0.72
46 0.61
(B) Inlet temperature (°C) Correction factor
25 1
30 1
35 1
40 0.82
45 0.69
50 0.58
55 0.45
62 0.34
(C) Inlet pressure (barg) Correction factor
5 0.9
6 0.97
7 1
8 1.03
9 1.06
10 1.08
11 1.1
12 1.12
13 1.13
Instruction book
2920 7210 40 35
