Atlas Copco F6 User Manual

Unit F45 F60 F75 F100 F120 F160
Nominal
power
(Amb.T.25°C;
Inlet T.35°C)
W 690 700 880 900 1100 1240
Nominal
current
amps 3.2 3.3 4.1 4.2 5 5.8
Minimum
cable size
(max cable
length 10 mt)
mm
2
1 1 1 1 1.5 1.5
Fan motor
protection
IP 54 54 54 54 54 54
Unit F200 F230 F285 F335 F400
Tension-
Phases-
Frequency
V/Ph/Hz 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Maximum
power
(Amb.T.45°C;
Inlet T.55°C)
W 2100 2370 2400 3800 4050
Maximum
current
amps 9.8 11 11.2 18.2 19.3
Nominal power
(Amb.T.25°C;
Inlet T.35°C)
W 1400 1620 1650 2650 2900
Nominal current amps 6.6 7.5 7.7 12.5 16.6
Minimum cable
size (max cable
length 10 mt)
mm
2
2.5 2.5 2.5 2.5 2.5
Fan motor
protection
IP 54 54 54 54 54
Piping Conditions
Unit F6 F11 F18 F25 F35
Air connections (Male) G3/4" G3/4" G3/4" G3/4" G1"
Condensate
drain (rubber
pipe)
mm 8 8 8 8 8
Unit F45 F60 F75 F100 F120 F160
Air connections (Male) G1" G1" G1.5" G1.5" G1.5" G2"
Condensate
drain (rubber
pipe)
mm 8 8 8 8 8 8
Instruction book
34 2920 7210 40
