Atlas Copco F6 User Manual

Unit F200 F230 F285 F335 F400
Total amount gr 1200 1500 1500 2300 2400
Net mass
(approx.)
kg 104 108 121 170 176
Net dimensions (approx.)
Length mm 752 752 752 928 928
Width mm 745 800 800 800 800
Height mm 960 1020 1020 1126 1126
Packing weight
(approx.)
kg 108 112 125 174 180
Packing dimensions (approx.)
Length mm 850 850 850 1030 1030
Width mm 850 900 900 900 900
Height mm 1040 1100 1100 1200 1200
Electrical data
Unit F6 F11 F18 F25 F35
Tension-
Phases-
Frequency
V/Ph/Hz 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Maximum
power
(Amb.T.45°C;
Inlet T.55°C)
W 350 360 390 400 460
Maximum
current
amps 2.5 2.6 2.8 2.9 3
Nominal power
(Amb.T.25°C;
Inlet T.35°C)
W 220 230 350 360 370
Nominal current amps 1.6 1.7 2.6 2.7 2.8
Minimum cable
size (max cable
length 10 mt)
mm
2
1 1 1 1 1
Fan motor
protection
IP 42 42 42 42 42
Unit F45 F60 F75 F100 F120 F160
Tension-
Phases-
Frequency
V/Ph/Hz
230/1/5
0
230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Maximum
power
(Amb.T.45°C;
Inlet T.55°C)
W 1020 1030 1270 1300 1450 1830
Maximum
current
amps 4.7 4.8 6.1 6.2 7 8.5
Instruction book
2920 7210 40 33
