8.5 Technical data Elektronikon® controller
General
Supply voltage
24V AC/16 VA 50/60Hz (+40%/-30%)
24V DC/0.7 A
Type of protection
IP54 (front)
IP21 (back)
Ambient and temperature condition
IEC60068-2
Operating temperature range
Storage temperature range
-10°C.....+60°C (14°F.....140°F)
-30°C.....+70°C (-22°F.....158°F)
Permissible humidity
Relative humidity 90%
No condensation
Noise emission
IEC61000-6-3
Noise immunity
IEC61000-6-2
Mounting
Cabinet door
Digital outputs
Number of outputs
9 (Elektronikon® Graphic controller - p.n. 1900 5200 10.....1900
5200 19)
Type
Relay (voltage free contacts)
Related voltage AC
250 V AC/10 A Max.
Related voltage AC
30 V DC/10 A Max.
Digital inputs
Number of inputs
10 (Elektronikon® Graphic controller - p.n. 1900 5200 10.....1900
5200 19)
Supply by controller
24 V DC
Supply protection
Short circuit protected to ground
Input protection
Not isolated
Analog inputs
Number of pressure inputs
2 (Elektronikon® Graphic controller - p.n. 1900 5200 10.....1900
5200 19)
Number of temperature inputs
5 (Elektronikon® Graphic controller - p.n. 1900 5200 10.....1900
5200 19)
