(9) Manual condensate drain
(10) Power switch, dryer
(11) Power switch, compressor
GX 7 Full-Feature on 200 l receiver
(1) Power supply cable, dryer
(2) Power supply cable, compressor
(3) Cooling air inlet
3.3 Electrical connections
Always disconnect the power supply before working on the electrical circuit!
