Atlas Copco GX 2 EP User Manual

50 Hz 10 bar
Compressor
type
GX 2 GX 3 GX 4 GX 5 GX 7
Frequency Hz 50 50 50 50 50
Maximum
(unloading)
pressure, Pack
bar(e) 10 10 10 10 10
Maximum
(unloading)
pressure, Pack
psig 145 145 145 145 145
Maximum
(unloading)
pressure, Full-
Feature
bar(e) 9.75 9.75 9.75 9.75 9.75
Maximum
(unloading)
pressure, Full-
Feature
psig 141 141 141 141 141
Nominal working
pressure
bar(e) 9.5 9.5 9.5 9.5 9.5
Nominal working
pressure
psig 138 138 138 138 138
Pressure drop
over dryer
bar(e) 0.15 0.15 0.15 0.15 0.25
Pressure drop
over dryer
psig 2.18 2.18 2.18 2.18 3.62
Motor shaft speed rpm 2840 2840 2840 2840 2940
Set-point,
thermostatic valve
˚C 71 71 71 71 71
Set-point,
thermostatic valve
˚F 160 160 160 160 160
Temperature of air
leaving receiver
(approx.), Pack
˚C 33 33 33 33 33
Temperature of air
leaving receiver
(approx.), Pack
˚F 91 91 91 91 91
Pressure dew-
point, Full-Feature
˚C 3 3 3 3 3
Pressure dew-
point, Full-Feature
˚F 37 37 37 37 37
Power input, Pack
at maximum
working pressure
kW 3.8 4.1 4.9 6.6 9.0
Power input, Pack
at maximum
working pressure
hp 5.1 5.5 6.57 8.85 12.27
Instruction book
64 2920 7105 31
