Atlas Copco LE 3 User Manual

2920 7089 80 13
Instruction book
Reference
Description
Gp Air pressure gauge
M Motor
MDR Air pressure switch
Me Electric motor
Mp Petrol engine
P1 Hourmeter, running time
PD Pulsation damper
RV Pilot valve
S1 On/off switch
S2 On/off switch dryer
SG Oil sight glass
SV Safety valve
UA Unloader
US Blow-off silencer
Y1 Loading solenoid valve
Reference
Description
1 Cover
2 Air inlet silencer
3 Crankcase
4 Cooling pipe
5 Left cylinder
6 Right cylinder
7 Pictograph, see Pictographs
8 Electric cabinet
9 Dewpoint indicator
10 Refrigerant dryer
11 Lifting yoke
12 Towing handle
13 Fuel tank
Compressor variants
The compressor block includes:
 Crankcase (3) and cylinders (5) and (6)
 Air inlet filter (AF) and inlet silencer (2)
 Fan (FN)
 Air cooler piping
 Check valve (CV) or Unloader (UA)
 Safety valve (SV)
The Power Pack comprises:
