LSV39 SA12-125 EN Installation
© Atlas Copco Industrial Technique AB - 9839 0621 01
9
Installation
Installation Requirements
Air Quality
■
For optimum performance and maximum product life we recommend the use of compressed air with
a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration
type air dryer.
■
Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of
liquid water. Install the filter as close as possible to the product and prior to any other air preparation
units to avoid pressure drop.
For impulse/impact tools make sure to use lubricators adjusted for these tools. Regular lubricators will
add too much oil and therefore decrease the tool performance due to too much oil in the motor.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Both lubricated and lubrication free products will benefit from a small quantity of oil supplied from a lu-
bricator.
Air Lubrication Guide
Brand Air lubrication
Atlas Copco Optimizer (1 liter) 9090 0000 04
Q8 Chopin 46
Shell Shell Air Tool Oil S2 A 320
Compressed Air Connection
WARNING Risk of severe injury
Air under pressure can cause injury.
► Always shut off the air supply when not in use or before any adjustments.
► Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
► Always use the correct hose size and air pressure for the tool.
WARNING Compressed Air
High air pressure can cause severe damage and bodily injury.
► Do not exceed maximum air pressure.
► Make sure that there are no damaged or loose hoses or fittings.
For correct air pressure and hose size, see the Technical Product Data on - https://
servaid.atlascopco.com or www.atlascopco.com.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Installation Instructions
Visual inspection - tools and accessories
Inspect the tool and its parts visually before use.
The parts in the list below may vary depending on model.
