Atlas Copco LT 2

LT 3 230 (1-phase) 13.7 25
LT 3 230 9.3 16
LT 3 400 5.6 10
LT 5 230 15.7 25
LT 5 400 9.3 16
LT 7 230 20.3 25
LT 7 400 12.4 25
LT 10 400 14.7 25
60 Hz
Type voltage
(V)
overload relay
(A)
fuses
(A)
LT 2 230 8.1 10
LT 2 440 4.1 10
LT 3 440 5.7 10
LT 5 380 11.1 25
LT 5 440 9.8 16
LT 5 460 9.4 16
LT 7 230 25.1 40
LT 7 440 12.8 25
LT 7 575 8.3 10
LT 10 230 28.5 40
LT 10 460 14.5 25
LT 10 575 11.7 25
Settings of overload relay and fuses of compressors with Y-D starter
50 Hz
Type voltage
(V)
overload relay
(A)
fuses
(A)
LT 5 230 9.1 25
LT 5 400 5.4 16
LT 5 500 4.3 16
LT 7 230 12.2 25
Instruction book
46 2920 7089 90
