Compressor
type
LT 2 LT 3 LT 5 LT 7
Motor shaft
speed
r/min 1800 1800 1800 1800
Free air delivery
(Note 1)
l/s 3.6 4.7 7.9 10.9
Oil capacity l 0.8 0.8 0.8 1.4
Opening
pressure of
safety valve
bar(e) 16 16 16 16
Opening
pressure of relief
valve
bar(e) 6.5 6.5 6.5 6.5
Maximum sound pressure level (Note 2)
- Tank- mounted dB(A) 80 81 81 82
- Tank-mounted
with hood
dB(A) 67 68 68 72
- Base-mounted
with hood
dB(A) 65 66 66 70
50 Hz (20 bar)
Compres
sor type
LT 2 LT 3 LT 5 LT 7 LT 10 LT 15 LT 20
Maximum
working
pressure
bar(e) 20 20 20 20 20 20 20
Temperature at outlet valve, approx.
-
Unsilence
d
compress
or
ºC 37 49 60 43 56 76 90
- Silenced
compress
or
°C 45 57 68 51 64 84 96
Power
input at
max.
working
pressure
kW 2.04 2.56 4.21 5.33 6.97 9.76 12.2
Motor
shaft
speed
r/min 1500 1500 1500 1500 1500 1500 1500
Free air
delivery
(Note 1)
l/s 2.1 2.9 5.0 6.7 9.1 15.1 18.0
Oil
capacity
l 1 1 1 1.8 1.8 5.1 5.1
Instruction book
2920 7089 90 69
