Atlas Copco Power Focus 3000 Original Product Instructions

Safety Information Power Focus 3000
10
© Atlas Copco Industrial Technique AB - 9836 2156 01
Dimension drawings – Compact
Dimension drawings – Graph
Back panel – Compact
1.Digital input + Internal 24 V DC
2.Relays
3.Ground Fault Interrupter (GFI)
4.Serial #1 (RS232)
5.I/O Bus #1
6.I/O Bus #2
7.Remote start
8.Main fuse
9.Main power connector
10.Ground connection
11.Field bus card (optional)
12.RBU
13.Ethernet
14.Serial #2 (RS232)
15.Printer
16.Tool output
Keypad – Compact
1.Plus (+)
2.Minus (-)
3.Function (F)
4.Autoset
5.Question mark (?)
6.Enter
Back panel – Graph
1.Digital input + Internal 24 V DC
2.Relays
3.Ground connection
4.Main fuse
5.Ground Fault Interrupter (GFI)
6.Serial #1 (RS232)
7.I/O Bus #1
8.Main power connctor
9.I/O Bus #2
10.Remote start
11.Field bus card (optional)
12.RBU
13.Ethernet
14.Serial #2 (RS232)
15.Printer
16.Tool connector

Atlas Copco Power Focus 3000 Specifications

General

Brand	Atlas Copco
Model	Power Focus 3000
Category	Control Systems
Language	English
