40 2954 2100 01
QAS 14 - 20 Pd
7.5.3 Wheel chocks
The option “wheel chocks” allows to park the generator on sloping
ground. Place wheel chocks in front of or behind the wheels to
immobilize the generator.
7.5.4 Lighting tower
The "Lighting tower" option provides an undercarriage (frame,
axle and towbar) and 6 halogen projectors of 1500 W each. The
lighting tower is very useful for construction sites where no elec-
tricity nor lighting is available.
Before raising the tower, install the four props for stability. To
switch the lamps on, plug the connector of the power supply cables
towards the lamps in outlet socket X3 of the generator.
To maintain the lighting tower
– Refer to the maintenance instructions mentioned in the chapter deal-
ing with the "Undercarriage" option.
– Check the condition of the tower, the tightness of its bolts and the
fixation of the elevation cable at least twice a year.
Do not use the handles on the lighting tower for tow-
ing or lifting the generator.
!
