Instruction manual
2954 2100 01 45
Alternator 4)
Standard IEC34-1 IEC34-1
ISO 8528-3 ISO 8528-3
Make NEWAGE NEWAGE
Model BCI 184 E1 BCI 184 E1
Rated output, class H temp. rise 20 kVA 25.3 kVA
rating type acc. ISO 8528-3
BR BR
Degree of protection IP 23 IP 23
Insulation stator class H H
Insulation rotor class H H
Number of wires 12 12
Engine 4)
Standard ISO 3046 ISO 3046
ISO 8528-2 ISO 8528-2
Type PERKINS 404C-22 404C-22
Rated net output 18.5 kW 20.7 kW
rating type acc. ISO 3046-7
ICXN ICXN
Coolant water water
Combustion system direct injection direct injection
Aspiration natural aspirated natural aspirated
Number of cylinders 4 4
Swept volume 2.216 l 2.216 l
Speed governing mechanical mechanical
(optional) electronic electronic
Capacity of oil sump 10.6 l 10.6 l
capacity of cooling system 4.6 l 4.6 l
Electrical system 12 Vdc 12 Vdc
Power circuit
Circuit-breaker, 3ph
Number of poles 4 4
Thermal release It (Thermal release is higher at 25°C) 32 A 32 A
Magnetic release Im 3..5xIn 3..5xIn
Circuit-breaker, 3ph, lower voltage
Number of poles (optional) 3 4
Thermal release It (Thermal release is higher at 25°C) 50 A 63 A
Magnetic release Im 3..5xIn 3..5xIn
Fault current protection
Residual current release IDn 0.030-30 A 0.030-30 A
Insulation resistance (optional) 10-100 kOhm -
Outlet sockets domestic (1x) none
2p + E
16A 230V
CEE form (1x)
3p + N + E
16A + 400V
CEE form (1x)
3p + N + E
32A + 400V
Unit
Dimensions (LxWxH) 2070 x 870 x 1188 mm 2070 x 870 x 1188 mm
Weight net mass 946 kg 946 kg
Weight wet mass 994 kg 994 kg
