Introduction STa 6000 User Guide
16 (324) 9836 8243 01 Edition 3.1
Nominal Torque (T) Measured torque shown on display
500 < T 5000
M 1000
no digits after decimal point
Measured torque < 1000
one digits after decimal point
T > 5000
no digits after decimal point
NOTE: In the above table, the Unit of Measurement of the torque can be set according to the
following available options: N·m, kgf·m, kgf·cm, lbf·ft, lbf·in, ozf·ft, ozf·in, kp·m, dN·m , kN
Sampling frequency:
- Click-wrench test: 2 kHz
- Power tool test: 5 kHz
- Peak test: 1 kHz
- Pulse tool and ACTA pulse tool test: 10 kHz
Maximum number of identifier strings: 1000
Units of Measurement supported: N·m, kgf·m, kgf·cm, lbf·ft, lbf·in, ozf·ft, ozf·in, kp·m, dN·m , kN
EXTERNAL POWER SUPPLY
Input power: 100 ÷ 240 VAC, 50 ÷ 60 Hz
AC Power Consumption: 21 W maximum
Output: 6VDC, max 3.0A
BATTERY PACK
Battery power supply: 3.75 V, 6.8 Ah
Battery type: Lithium-ion (Li-ion)
Endurance: 8 hours in normal usage, 6 hours in continuous operation (1 test every 30 seconds)
Recharging max. 8 hours
BATTERY CHARGER
Input power: 100 ÷ 230 VAC
AC Power Consumption: 70 W maximum
Output: 4.2 VDC 13 W maximum
Overvoltage category: II
