Introduction STa 6000 User Guide
18 (324) 9836 8243 01 Edition 3.1
INTERFACES
MiniUSB 2.0 port
Transducer connector: 19 poles military connector for:
- IRTT-B and IRTT
- SRTT-B and SRTT
- MRTT-B and MRTT
- MRTT-C
- SRTT-L
- mV/V torque transducers (0.4 mV/V to 2.5 mV/V, bridge resistance 350 to 1000 Ohm)
Barcode reader module (optional):
- Visible laser diode 650 nm
- Output power: 1 mW maximum
- Scan rate: 104 ± 12 scans/second (bi-directional)
- Scan angle: 47° ± 3°
- Scan patterns: Linear
- Minimum Print contrast: Minimum 20% absolute dark/light reflectance measured at 650 nm
- Ambient light:
o Sunlight: 10000 ft candles (107640 Lux)
o Artificial: 450 ft candles (4484 Lux)
- EMI/RFI: FCC Part 15 Class B, EN 55024/CISPR 22, AS 3548, VCCI
- Laser Safety: IEC 60825 class 2
IRC-W dual band radio module (optional):
- Minimum IRC-W module firmware version: 2.14
- Type: 802.11a/b/g/n
- Frequencies:
CHANNEL CENTER FREQUENCY (MHz) EU USA Max. E.I.R.P. (mW)
1
2412 YES YES
0.9
2
2417 YES YES
3
2422 YES YES
4
2427 YES YES
5
2432 YES YES
6
2437 YES YES
0.79
7
2442 YES YES
8
2447 YES YES
9
2452 YES YES
10
2457 YES YES
