- 39 -
Technical specifications
COMPRESSOR / ENGINE SPECIFICATIONS
REFERENCE CONDITIONS
The inlet conditions are specified at the air inlet grating outside the canopy.
LIMITATIONS
Designation
XAHS 38 Kd XAS 58 Kd XAS 68 Kd XAS 48 G Kd XATS 68 Kd XAS 78 Kd XAS 88 Kd XAS 68 G Kd
Absolute inlet pressure bar 1 1 1 1 1 1 1 1
psi 14.5 14.5 14.5 14.5 14.5 14.5 14.5 14.5
Relative air humidity % 0 0 0 0 0 0 0 0
Air inlet temperature °C 20 20 20 20 20 20 20 20
°F 68 68 68 68 68 68 68 68
Nominal effective working
pressure
bar 12 7 7 7 10.3 7 7 7
psi 175 100 100 100 150 100 100 100
Designation XAHS 38 Kd XAS 58 Kd XAS 68 Kd XAS 48 G Kd
Minimum effective receiver pressure bar 2 2 2 2
psi 30 30 30 30
Maximum effective receiver pressure,
compressor unloaded
bar 13.5 8.8 8.8 8.8
psi 200 125 125 125
Maximum ambient temperature
at sea level
without aftercooler °C 50 50 50 50
°F 122 122 122 122
with aftercooler °C 45 45 45 45
°F 113 113 113 113
Minimum starting temperature °C -10 -10 -10 -10
°F 14 14 14 14
Minimum starting temperature, with coldstart equipment °C -20 -20 -20 -20
°F -4 -4 -4 -4
