DIMENSIONS
3152 [124,1]
2204 [86,8]
186 [7,3]
3403 [134,0]
1140 [44,9]
2514 [99,0]
401[15,8]
884 [34,8]
1497 [58,9]
1140 [44,9]
1435 [56,5]
1435 [56,5]
2514 [99,0]
888 [34,9]
1171 [46,1]
3106 [122,3]
186 [7,3]
1346 [53,0]
1130 [44,5]
940 [37,0]
2306 [90,8]
2802 [110,3]
235 [9,3]
1346 [53,0]
1130 [44,5]
940 [37,0]
Weight (maximum): see indication on dataplate
9822 0106 00 - Adjustable tow bar no brakes
9822 0105 00 - Adjustable tow bar with brakes
