Atlas Copco XAHS 70 KD8 WUX User Manual

- 47 -
Unit
1)
Air required for engine and compressor cooling, for combustion and for compression.
Alternator
Designation Unit
All units
Capacity of compressor oil
system
l 7.7
US gal 2.0
Net capacity of air receiver l 16.7
US gal 4.4
Capacity of fuel tank l 60
US gal 16
Air volume at inlet grating
(approx.)
1)
m
3
/s 0.93
cuft/s 32.8
Designation Unit XAS 48 G + XAS 68 G
Voltage AC V 110 230/400 230/400
Rated output kVA 6 6 12
Model S16F T16F T20FS
Protection Earth fault relay Earth fault relay IT relay Earth fault relay IT relay
Sockets 1x 110V/1ph/32A
2x 110V/1ph/16A
1x 400V/3ph/10A
2x 230V/1ph/10A
2x 400V/3ph/16A
1x 230V/1ph/16A
Protection rating IP 23
Standard IEC 34-1
Box_2-2.book Page 47 Friday, October 27, 2017 3:48 PM

Atlas Copco XAHS 70 KD8 WUX Specifications

General

Brand	Atlas Copco
Model	XAHS 70 KD8 WUX
Category	Air Compressor
Language	English
