Atlas Copco XAHS 70 KD8 WUX

- 46 -
DESIGN DATA
Compressor
Engine
* V1505: 6 kVA generator
V1505-T: 12 kVA generator
Number of compression stages: 1
Designation
Unit
XAHS 38 Kd XAS 58 Kd XAS 68 Kd XAS 48 G Kd XATS 68 Kd XAS 78 Kd XAS 88 Kd XAS 68 G Kd
Make Kubota Kubota Kubota Kubota Kubota Kubota Kubota Kubota
Type V1505 V1505 V1505 V1505-T* V1505-T V1505-T V1505-T V1505-T
Coolant Liquid Liquid Liquid Liquid Liquid Liquid Liquid Liquid
Number of cylinders 4 4 4 4 4 4 4 4
Bore mm 78 78 78 78 78 78 78 78
in 3.07 3.07 3.07 3.07 3.07 3.07 3.07 3.07
Stroke mm 78.4 78.4 78.4 78.4 78.4 78.4 78.4 78.4
in 3.09 3.09 3.09 3.09 3.09 3.09 3.09 3.09
Swept volume l 1.498 1.498 1.498 1.498 1.498 1.498 1.498 1.498
cu in 91.4 91.4 91.4 91.4 91.4 91.4 91.4 91.4
Output according to
ISO 9249 G at normal shaft
speed
kW 26.5 26.5 26.5 33 33 33 33 33
BHP 36 36 36 45 45 45 45 45
- Load factor % 100 100 100 100 100 100 100 100
Capacity of oil sump:
- Refill (max.) with filter change l 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
US gal 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
Capacity of cooling system l 7.2 7.2 7.2 7.2 7.2 7.2 7.2 7.2
US gal 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9
