Atlas Copco XAS 67 Dd C3 APP - Page 106

- 106 -
Unit
1)
Air required for engine and compressor element cooling, for combustion and for compression.
Designation
XAS 67 -
XAS 130
XAS 67 -
XAS 130
(Generator)
XATS 67 -
XATS 125
XAS 77 -
XAS 150
XAS 97 -
XAS 185
XAS 97 -
XAS 185
(Generator)
Capacity of compressor oil system l 8 8 8 8 8 8
US gal 2.1 2.1 2.1 2.1 2.1 2.1
Net capacity of air receiver l 16.7 16.7 16.7 16.7 16.7 16.7
US gal 4.4 4.4 4.4 4.4 4.4 4.4
Air volume at inlet grating (approx.)
1)
m
3
/s 0.85 0.85 0.85 0.93 1.2 0.85
cuft/s 30 29 30 33 42.4 29
Capacity of fuel tank l 808080808080
US gal 21.1 21.1 21.1 21.1 21.1 21.1
