DESIGN DATA FOR GENERATOR
Alternator
Electrical power circuit
Designation
XAS 67 - XAS 130, XAS 97 - XAS 185
110V - 6 kW 230V - 3 ph -
6 kVA
230V - 3 ph -
12.5 kVA
230/400V - 3 ph -
6 kVA
230/400V - 3 ph -
12.5 kVA
Standard IEC 34-1 IEC 34-1 IEC 34-1 IEC 34-1 IEC 34-1
Make MECC ALTE MECC ALTE MECC ALTE MECC ALTE MECC ALTE
Model MR-1 -180/2 TR-1 -160/2 T20 FS -160/A TR-1 -160/2 T20 FS -160/A
Rated output kVA 6 6 12.5 6 12.5
Degree of protection IP 23 23 23 23 23
Insulation - stator classHHHHH
- rotor classHHHHH
Number of phases 13333
Number of leads 46666
Designation
XAS 67 - XAS 130, XAS 97 - XAS 185
110V - 6 kW 230V - 3 ph -
6 kVA
230V - 3 ph -
12.5 kVA
230/400V - 3 ph -
6 kVA
230/400V - 3 ph -
12.5 kVA
Rated continuous active power COP kW 5.5 4.8 9.6 4.8 9.6
Rated power factor (lagging) 1 0.8 0.8 0.8 0.8
Rated continuous apparent power 1 ph COP kVA 5.5 4 3.7 4 3.7
Rated voltage 1ph line to line V 110 230 230 230 230
Rated current 1ph A 50 16 16 16 16
Frequency droop % <5 <5 <5 <5 <5
Rated continuous apparent power 3 ph COP kVA - 6 12 6 12
Rated voltage 3ph line to line V - 230 230 400 400
Rated current 3ph A - 15 30.1 8.7 17.4
Frequency droop % <5 <5 <5 <5 <5
