Atlas Copco XAS 67 Dd C3 APP User Manual

- 48 -
TOWING INSTRUCTIONS
Label on towbar, towing instructions Non-adjustable towbar with standard support leg without
brakes
For both non-adjustable - and adjustable towbar, the
towbar should be as level as possible and the
compressor and towing eye end in a level position.
Push the hand brake lever (3) completely downwards
and connect breakaway cable (4) to the vehicle.
Secure jockey wheel (2) or support leg (1) in the
highest possible position. The jockey wheel is
prevented from turning.
Adjustable towbar with jockey wheel and brakes
Towing position of jockey wheel
Before towing the compressor, ensure
that the towing equipment of the vehicle
matches the towing eye or ball
connector, and ensure that the hood is
closed and locked properly.
(1)
(4)
(2)
(3)
(4)
(2)
(2)
