The Status data submenu gives information regarding the status of the compressor protection functions
(shut-down, shut-down warning and service warning) and allows resetting of a shut-down, motor overload
and service condition.
Procedure
Starting from the Main screen (see Main screen menu):
• Press the key “Menu” (F1): the option “Status Data” will be followed by a horizontal arrow.
• Press the tabulator key (2).
No message exists
• General alarm LED (1) is out and the message on the display will indicate that all conditions are
normal:
“All Conditions Are OK”
.
.
“Menu” “Help”
F1 F2 F3
A shut-down message exists
• In case the compressor is shut down, LED (1) will blink.
• In case of a shut-down due to too high a temperature at the outlet of the compressor element:
“Element Outlet” 114˚C
.
“Shutdown” “Maximum” 110˚C
“Menu”*** “Help” ***”Reset”
F1 F2 F3
• The indicators (***) are blinking. The screen shows the actual reading and the shut-down setting.
• It remains possible to scroll through other menus, e.g. to check the values of other parameters.
When returning to the “Status Data” menu, the option “Shutdowns” will blink. This option can be
selected by pressing the tabulator key (2) to return to the above shut-down screen.
Shut-down reset
• Switch off the voltage and remedy the trouble. After remedying and when the shut-down condition
has disappeared, switch on the voltage and press the key “Reset” (F3).
• Press the keys “Menu” and “Mainscreen” to return to the Main screen and restart the compressor by
means of start button (3).
A shut-down warning message exists
A shut-down warning level is a programmable level below the shut-down level.
Instruction book
2920 1815 04 87
