Maximum temperature of cooling water inlet - open
circuit
40 °C
104 °F
Maximum temperature of cooling water outlet 50 °C
122 °F
Maximum temperature of cooling water outlet of
compressors with Energy Recovery- closed circuit
90 °C
194 °F
Maximum rise of cooling water temperature (for
compressors without Energy Recovery)
up to 35 °C
up to 63 °F
Maximum rise of cooling water temperature (for
compressors with Energy Recovery)
up to 70 °C
up to 126 °F
Maximum rise of cooling water temperature in the
Energy Recovery circuit of Full-Feature
compressors
up to 10 °C
up to 18 °F
Maximum pressure of cooling water inlet 10 bar(g)
145 psi(g)
Minimum - maximum oil pressure 1.2–4.5 bar(g)
17.4–65.3 psi(g)
Minimum - maximum oil temperature (for standard
compressors)
0-70 °C
32- 158 °F
Minimum - maximum oil temperature (for High
Ambient Temperature compressors)
0 - 80 °C
32- 176 °F
Working pressure: Minimum-
Maximum (bar(g))
Pack Full-Feature
7 bar - 60 Hz 4–7.5 5–7.5
7.5 bar - 50 Hz 4–7.5 5–7.5
8.6 bar - 50/60 Hz 4–8.6 6–8.6
10 bar - 50 Hz 4–10 7–10
10.4 bar - 60 Hz 4–10.4 8–10
13 bar - 50/60 Hz 9–13 -
Working pressure: Minimum-
Maximum (psi(g))
Pack Full-Feature
101 psi - 60 Hz 58–73 73–102
109 psi - 50 Hz 58–73 73–109
125 psi - 50/60 Hz 58–125 87–125
145 psi - 50 Hz 58–145 102–145
150 psi - 60 Hz 58–151 116–145
188 psi - 50/60 Hz 131–189 -
Instruction book
312 2920 1815 04
