Atlas Copco ZT30 - ZT;ZR30 up to ZT;ZR45 IEC; ZT;ZR30 up to ZT;ZR45 CSA;UL

Instruction book
2920 1472 03 58
7.3.3 ZT/ZR30 up to ZT/ZR45 IEC
Compressor
type
Voltage
supply
Frequency Overload relay
F21
Circuit
breaker
Q15
(ZT only)
Main fuses
(customer's
installation)
gL/gG (IEC)
ZT/ZR30 200 V 50 Hz 77.7 A 5.4 A 160 A
ZT/ZR30 200/220 V 60 Hz 71.6 A 5.5 A 160 A
ZT/ZR30 230 V 60 Hz 68.2 A 4.5 A 160 A
ZT/ZR30 230 V 50 Hz 67.2 A 4.7 A 160 A
ZT/ZR30 380 V 60 Hz 40.9 A 2.4 A 100 A
ZT/ZR30 400 V 50 Hz 38.8 A 2.7 A 100 A
ZT/ZR30 460 V 60 Hz 34.1 A 2.4 A 80 A
ZT/ZR30 500 V 50 Hz 31.1 A 2.2 A 80 A
ZT/ZR37 200 V 50 Hz 90.5 A 5.4 A 200 A
ZT/ZR37 200/220 V 60 Hz 86.5 A 5.5 A 200 A
ZT/ZR37 230 V 60 Hz 81.7 A 4.5 A 200 A
ZT/ZR37 230 V 50 Hz 79.0 A 4.7 A 200 A
ZT/ZR37 380 V 60 Hz 48.3 A 2.4 A 125 A
ZT/ZR37 400 V 50 Hz 45.6 A 2.7 A 100 A
ZT/ZR37 460 V 60 Hz 40.9 A 2.4 A 100 A
ZT/ZR37 500 V 50 Hz 36.1 A 2.2 A 80 A
ZT/ZR45 200 V 50 Hz 112.1 A 8.0 A 250 A
ZT/ZR45 200/220 V 60 Hz 106.1 A 11.0 A 250 A
ZT/ZR45 230 V 60 Hz 100.0 A 9.7 A 250 A
ZT/ZR45 230 V 50 Hz 97.3 A 8.0 A 200 A
ZT/ZR45 380 V 60 Hz 59.1 A 6.6 A 125 A
ZT/ZR45 400 V 50 Hz 56.1 A 4.7 A 125 A
ZT/ZR45 460 V 60 Hz 50.0 A 5.6 A 125 A
ZT/ZR45 500 V 50 Hz 44.9 A 3.8 A 100 A
7.3.4 ZT/ZR30 up to ZT/ZR45 CSA/UL
Compressor
type
Voltage
supply
Frequency Overload
relay F21
Circuit
breaker
Q15
(ZT only)
Main fuses
(customer's
installation)
CSA HRC/UL RK5
ZT/ZR30 200 V 60 Hz 71.6 A 5.5 A 200 A / 2x100 A
ZT/ZR30 230 V 60 Hz 68.2 A 4.5 A 200 A / 2x100 A
ZT/ZR30 460 V 60 Hz 34.1 A 2.4 A 100 A / 90 A
ZT/ZR30 575 V 60 Hz 27.0 A 1.9 A 80 A / 70 A
ZT/ZR37 200 V 60 Hz 86.5 A 5.5 A 225 A / 2x110 A
ZT/ZR37 230 V 60 Hz 81.7 A 4.5 A 225 A / 2x110 A
ZT/ZR37 460 V 60 Hz 40.9 A 2.4 A 110 A / 100 A
ZT/ZR37 575 V 60 Hz 32.1 A 1.9 A 100 A / 90 A
ZT/ZR45 200 V 60 Hz 106.1 A 11.0 A 250 A / 2x125 A
ZT/ZR45 230 V 60 Hz 100.0 A 9.7 A 250 A / 2x125 A
ZT/ZR45 460 V 60 Hz 50.0 A 5.6 A 150 A / 125 A
ZT/ZR45 575 V 60 Hz 39.2 A 4.5 A 125 A / 100 A
