Figure 28-20. I/O Pin Source Current vs. Output Voltage (Vcc = 2.7V)
Figure 28-21. I/O Pin Sink Current vs. Output Voltage (Vcc = 5V)
I/O PIN SOURCE CURRENT vs. OUTPUT VOLTAGE (Vcc = 2.7V)
-30
-25
-20
-15
-10
-5
0
0.5 1 1.5 2 2.5 3
V
OH
(V)
I
OH
(mA)
85°C
25°C
-40°C
I/O PIN SINK CURRENT vs. OUTPUT VOLTAGE (Vcc = 5V)
0
10
20
30
40
50
60
70
80
90
0 0.5 1 1.5 2 2.5
V
OL
(V)
I
OL
(mA)
85°C
25°C
-40°C
