1.2.3. SPECIFICATIONS
The following tables provide information pertaining to the operational, electrical, mechanical,
optical and environmental characteristics for the monocular.
Table 1-1. Specifications
ITEM
ODIN-31C
ODIN-31CW
ODIN-31D
ODIN-31DW
ODIN-32C
ODIN-32CW
ODIN-32D
ODIN-32DW
ODIN-6WB
ODIN-6WBW
ODIN-61B
ODIN-61BW
Sensor (micro-
bolometer)
320 x 240 px 640 x 480 px
Type
Uncooled
Material
Vanadium oxide (VOx)
Frame Rate
30 Hz 60 Hz 30 Hz 60 Hz 30 Hz 30 Hz
Pixel Size
17 mm 35 mm 17 mm 35 mm
Spectral
Response
7-14 µm
Pixel Size
17 µm
Optical
Magnification
1x 2x 0.5x 1x
E-Zoom
2x, 4x 4x, 8x 1x, 2x, 4x 2x, 4x, 8x
FOV
24° x 18° 15° x 11° 48° x 36° 24° x 18°
Focus Range
0.25 m to infinity
Diopter
Adjustment
-6 to +4
Eye Relief
27 mm
