ATN ODIN - General Operation Information; Controls and Indicators

3-2
3.1. GENERAL INFORMATION
3.1.1. GENERAL
This section contains instructions for operation of Odin. The func-
tion of controls and indicators is explained.
CAUTION
The Odin scope is a precision electron-optical instrument and
must be handled carefully at all times.
3.1.2. CONTROLS AND INDICATION
The Odin scope is designed to adjust for different users and cor-
rects for most differences. The controls for the scope are shown
or described in Figure 3.1. and Tables 3-1.
FIGURE 3.1. CONTROLS
EYEPIECE DIOPTER
ADJUSTMENT RING
FRONT LENS
ASSEM BLY/ VPT
ON-OFF SWITCH
ENTER BUTTON
UP BUTTON
DOWN BUTTON
