4-6
FIGURE 4.1. REINSTALLING THE NECK PAD
c. Lacing the Sliding Bar Buckles
FIGURE 4.2. THREADING THE SLIDING BAR BUCKLES
NECK PAD STRAP
LOWER STRAP
RETENTION TAB
UPPER STRAP
RETENTION TAB
MOVEABLE
SLIDING BAR
FIXED
SERRATED BAR
