4 5
2. SPECIFICATIONS
OTS-XLT 160 2-8x OTS-XLT 160 2.5-10x
Lens 19 mm 25 mm
Sensor 160x120 px / 17 µm 50 Hz
Magnification 2 – 8× 2.5 – 10×
Field of view, degrees 8.2
×
6.2 6.5
×
4.9
Core ATN Obsidian Core LT
Micro Display 720
×
540 px
IP rating IP67
Charging USB, type C
Video Record Resolution 720
×
576 px
Internal Storage 8 Gb
Color modes White Hot / Black Hot / Red Hot / Color
Battery life (Li-ion) ≈10 hr
Operating Temperature -4°F to +131°F / -20°C to 55°C
Dimensions 6.85”
×
2.63”
×
2.08” / 174
×
67
×
53 mm
Weight 0.81 lb/370 g
Human Detection Range, m 670 850
Human Recognition Range, m 335 425
Human Identification Range, m 170 210
Warranty 2 years
3. OVERVIEW
3.1. BRIEF DESCRIPTION
The handheld thermal monocular is a handheld device for observation, high-
est temperature target tracking, distance measurement. The high-sensitivity
built-in thermal detector provides you with clear view even in total darkness.
The device is mainly applied to outdoor scenarios such as patrolling, law
enforcement, search and rescue, drug enforcement, anti-smuggling, hiking,
travel, and hunting, etc.
3.2. FUNCTION
Distance Measurement
The device can detect the distance between the target and the observation
position.
Highest Temperature Tracking
The device can detect the highest temperature in the scene and mark the
spot. This function varies according to different camera models.
1. SAFETY INSTRUCTION
These instructions are intended to ensure that the user can use the product correctly
to avoid danger or property loss
.
Transportation
• Keep the device in original or similar packaging while transporting it.
• Keep all wrappers after unpacking them for future use. In case of any failure, you
need to return the device to the factory with the original packaging. Transportation
without the original packaging may result in damage to the device.
• Do not drop the product or subject it to physical shock. Keep the device away from
magnetic interference.
Power Supply
• You will need to obtain a compatible charging block. Input voltage should meet
the Limited Power Source (5 V DC, 2 A) according to the IEC61010-1 standard.
• Make sure the plug is properly connected to the power socket.
• DO NOT connect multiple devices to one power adapter, to avoid over-heating or
fire hazards caused by overload.
Battery
• The built-in battery cannot be removed. Please contact the manufacture for repair
if necessary.
• For long-term storage of the battery, make sure it is fully charged every half year
to ensure the battery quality. Otherwise, damage may occur.
Maintenance
• If the product does not work properly, please contact your dealer or the nearest
service center. We shall not assume any responsibility for problems caused by
unauthorized repair or maintenance.
• Wipe the device gently with a clean cloth and a small quantity of ethanol, if nec-
essary.
• If the equipment is used in a manner not specified by the manufacturer, the pro-
tection provided by the device may be impaired.
Operational Environment
• Make sure the operating environment meets the requirement of the device. The
operating temperature shall be -20°C to 55°C (-4°F to 131°F), and the operating
humidity shall be 95% or less.
• DO NOT expose the device to high electromagnetic radiation or dusty environ-
ments.
• DO NOT aim the lens at the sun or any other bright light.
Emergency
• If smoke, odor, or noise arises from the device, immediately turn off the power,
unplug the power cable, and contact the service center.
To Next Page
