10 11
5.5. SELECT SCENE
Depending on the environment which you operate you can select the appro-
priate scene: ie Forest, etc.
Steps
1. Hold
to go to the menu.
2. Select
and press to switch scene.
refers to recognition mode and is recommended in normal scene.
refers to Forest mode and is recommended in hunting environment.
3. Hold
to save settings and exit.
5.6. SET PALETTES
You can select different palettes to display the same scene in different
effects. Press to switch palettes.
White Hot
The hot part is light-colored in view. The higher the temperature is, the lighter
the color is.
Black Hot
The hot part is black-colored in view. The higher the temperature is, the
darker the color is.
5.2. FOCUS LENS
Slightly rotate the focus wheel to focus the objective lens.
Adjust Objective Lens
NOTE
DO NOT touch the lens directly with your finger, or place any sharp
objects near it.
This function varies according to different camera models.
5.3. ADJUST BRIGHTNESS
Hold ,
select and press to adjust brightness. In white hot mode,
the higher the value of brightness is, the brighter the image is. The image
effect in white hot mode is showed as picture below and effect in black hot
mode is opposite.
Adjust Brightness in White Hot Mode
5.4. ADJUST CONTRAST
Hold ,
select and press to adjust image contrast.
