PARAMETER SETTINGS CONTINUED...
BUTTON: Assign the COMPRESSOR ENABLE functionality to the selected footswitch.
Pressing the assigned footswitch will toggle between ACTIVE and BYPASS mode of
the COMPRESSOR.. Please note that the assigned footswitch must be in PRESET
ASSIGN mode.
LOOP
ENABLE: Turns the external effects LOOP on or off. Select ACTIVE to turn it on. Select
BYPASSED to turn it off. In AUX INPUT mode, the loop ENABLE serves no function.
(see loop MODES below)
MODE: Choose from the following 4 modes:
MUTE SEND: In MUTE SEND mode, the LOOP bypass/active state controls the
mute on the send jack only and the return jacks are always active. This allows any
effect tails (like in delays and reverbs) to continue to ring out and decay even after
the loop is BYPASSED.
MUTE RETURN: In MUTE RETURN mode, the LOOP bypass/active state controls
the mute on both the send and the return. This immediately mutes any external
effects connected to the LOOP once it is BYPASSED.
AUX INPUT/DI: In AUX INPUT mode, the LOOP acts like an auxiliary input for
connection with external music players. The input will mix with directly to the
outputs without any effects. In this mode, the send jack remains active and can be
used as an additional unprocessed guitar DI signal.
EXPRESSION: in EXPRESSION mode, the effects loop is disabled and may be used
with a special adapter cable (available through Atomic Amps) to accommodate two
standard expression pedals (for controlling effect parameters with pedals in real-
time). For expression pedals to work with the loop jacks, the LOOP must be put into
EXPRESSION mode. PLEASE NOTE: This mode is only available on the AMPLIFIRE
since the AMPLIFIRE12 has dedicated expression pedal inputs.
LOOP INSERT: Determines the location of the LOOP. For details, please see the
EFFECTS LOOP section above.
SEND LEVEL (dB): Adjusts the relative output of the SEND jack to help match with
external effects processor inputs.
RETURN LEVEL (dB): Adjusts the relative input gain of the RETURN jacks to help
match with external effects processor output levels.
PEDAL A/B: Displays the position of applicable expression pedal in percent (%). The
full heel position (minimum position) should display as near 0%. The full toe position
(maximum position) should display as near 100%. If you do not get a good range with
your pedal, you may calibrate it by pressing SAVE while on the PEDAL display. This
starts the PEDAL calibration function. (See the EXPRESSION PEDALS section for
more details).
