P.8
19
Attaching Gear box
18
Attaching Motor & Gear
Motor
(3500KV is good choice)
M2x4
1.2x5 O-ring
Spur gear
(42T)
Motor Gear
(19T)
Default setup
0.2mm
Toe-in block
M1.2x4
M2x8
M2x4
