Atomic DRZ - Wheel and Electronic System Installation; 22. Attaching tire & wheel; 23. Attaching electronic sys

P.10
22
Attaching tire & wheel
23
Attaching electronic sys
Lock nut
Lock nut
Front tire
Front tire
Rear tire
Rear tire
Suggest
1 or +1.5 offset wheel
0.5 or 1.0 offset wheel
M2x6KM
body mount nut
Speed controller
RX
Gyro
Double-sided Tapes
Double-sided Tapes
2.0mm Thick Double-sided Tape
to minimize vibration to gyro.
!
