P.3
Attaching Upper suspension mount
6
M2x6
7
Attaching Steering Assembly
3x6x2
Bearing
3x6x2
Bearing
Steering Block
Front Axles
Linkage Ball
(3.5mm)
Linkage Ball
(4mm)
Linkage Ball
(4mm)
3x6x2
Bearing
3x6x2
Bearing
Front Axles
Steering Block
Linkage Ball
(3.5mm)
Linkage Ball
(4mm)
Linkage Ball
(4mm)
