ATOMIC4DJ 61085P - DMX Protocol

If the light does not respond to commands from your controller check the following:
1.DMX cable is not connected to the unit or the output of the DMX controller.
2.DMX controller is OFF
3.Used cable is damaged or incorrect.
DMX PROTOCOL
CHANNEL VALUE FUNCTION
CH1
0 No use
1-22 Red
23-45 Green
46-68 Blue
69-91 Cyan
92-114 Yellow
115-137 Orange
138-160 Pink
161-183 Purple
184-206 Dark Blue
207-229 Light Green
230-252 White
253-255 Warm White
DMX Mode2 3 Channel
CHANNEL VALUE FUNCTION
CH1 0-255 MASTER DIMMER
CH2 0-255 RED
CH3 0-255 GREEN
CH4 0-255 BLUE
Atomic4Dj Par64 Led Slim RGB – www.Atomic4Dj.com
