Atomos SHOGUN 7 Quick Start Guide

3
HDMI Cable/s
To support 4Kp60 recording please use cables that support
HDMI 2.0 specication. Atomos have a range of 4Kp60 cables
with die cast connectors and coiled cables in a range of lengths
and connections (sold separately). See the full range of Atomos
HDMI cables on our website: www.atomos.com/hdmi-cables
Checklist
You will also need
q 1 x Shogun 7
q 1 x Master Caddy II
q 1 x AC/DC Power Adaptor
q 1 x EPP Carry Case
q 1 x Quick Start Guide
NOTE: The Carry Case has extra partitions for accessories.
Introduction
Thank you for purchasing the Atomos Shogun 7, utilizing
professional QuadLink SDI and HDMI 2.0 connectivity to record
professional 4Kp60 and high frame rate HD to Apple ProRes
®
,
ProRes RAW and Avid DNxHR (plus CDNG RAW up to 4Kp30).
A new 360 zone backlight is combined with our new screen
technology and controlled by the Dynamic AtomHDR engine to
show millions of shades of brightness and color, yielding
jaw-dropping results. It allows Shogun 7 to display 15+ stops
of real dynamic range on-screen. The panel is also incredibly
accurate, with ultra-wide color and 105% of DCI-P3 coverage.
Shogun 7 can also be used as a portable, quadview live switcher
and recorder on multi-camera shoots. Record up to four 1080p60
streams from the 4 x SDI inputs simultaneously as separate ISOs,
while cueing and switching in real-time. You can also record
a fth ‘program’ channel of the switched feed, and display the
resulting mixed output (via HDMI or SDI) live on set.

Atomos SHOGUN 7 Specifications

General

Internal	No
Product color	Black
Video capturing speed	60 fps
Maximum video resolution	3840 x 2160 pixels
Operating temperature (T-T)	0 - 40 °C
Power consumption (max)	33 W
Built-in display	Yes
Display diagonal	7.2 \

Weight and Dimensions

Depth	45 mm
Width	214 mm
Height	127 mm
Weight	709 g
