Atomos SHOGUN 7 Quick Start Guide

4
Using AC/DC Power Adaptor or Batteries
You can power the Shogun 7 using the supplied AC/DC power
adaptor, but if you plan to use batteries we recommend you fully
charge any batteries before use.
Choosing the right battery for your application
Size Cells Battery Life Function
5200mAh 4 Up to 1.5hrs monitor & record 4Kp30
7800mAh 6 Up to 2.2hrs monitor & record 4Kp30
We recommend using Atomos NP-F series batteries.
Power You will also need
SDI cables
If you are connecting via 6G or 12G SDI please ensure your cable
supports the Belden 1694A standard.
Media and Docking Station
Shogun 7 supports AtomX SSDmini, approved SSD media in a
Master Caddy II/III, and CFast II media in an AtomX CFast adapter.
To avoid potential data loss and/or write/read errors, Atomos
recommends using approved media only. For the most up-to-date
information on compatible media, please refer to: www.atomos.
com/drives
We also have Docking Stations suitable for use with Shogun 7
and compatible media. Available from your nearest authorised
Atomos reseller.

Atomos SHOGUN 7 Specifications

General

Internal	No
Product color	Black
Video capturing speed	60 fps
Maximum video resolution	3840 x 2160 pixels
Operating temperature (T-T)	0 - 40 °C
Power consumption (max)	33 W
Built-in display	Yes
Display diagonal	7.2 \

Weight and Dimensions

Depth	45 mm
Width	214 mm
Height	127 mm
Weight	709 g
