Model
FG24 / FS24
FG30 / FS30
FG36 / FS36
For refrigerant
Type
R410A
R410A
R410A
[g]
1500
2100
2100
Model
ROG24LBCB AO*G30LETL AO*G36LETL
Power supply
[V]
230 V / 50 Hz
Permitted power supply range
[V]
198 – 264 V / 50Hz
Max. sup. current
[A]
15.7
17.0
20.0
Fan
Air flow
rate
Cooling
[m
3
/h]
2850
3600
3800
Heating
2700
3600
3800
Type x number
[-]
Axial fan x 1
Motor power input
[W]
49
100
Noise level (pressure)
Cooling
[dB(A)]
53
53
54
Heating
54
55
55
Noise level (power)
Cooling
66
68
69
Heating
66
69
70
Heat exchanger
Dimension
(H x W x D)
[mm]
672 x 881 x 18.2
672 x 851 x 18.2
798 x 900 x 36.4
Fin spacing
1.30
Number of rows x
Number of tubes in one
row
[-] 2 x 32 2 x 38
Tube material
[-]
Copper
Fin material
[-]
Aluminium
Compressor
Type x number
[-]
Double rotary x1
Double rotary x 1
Motor power input
[W]
1200
2100
Oil in
Type
[-]
RB68
POE (RB68)
Amount
[cm
3
]
550
-
Housing
Material
[-]
Steel sheet
Colour
[-]
Beige
Dimension
(H x W x D)
Net dimensions
[mm]
716 x 820 x 315
830 x 900 x 330
Dimensions including
packaging
776 x 961 x 450
970 x 1050 x 445
Weight
Net weight
[kg]
42
61
Weight including
packaging
47
68
Connecting lines
Diameter
Liquid
[mm]
Ø6.35 (ø1/4 in.)
Ø9.52 (ø3/8 in.)
Gas
Ø15.88 (ø5/8 in.)
Ø15.88 (ø5/8 in.)
Without refrigerant
recharge
[m]
15*
20*
Max. length
30
50
Max. height difference
20
30
Operating range
Cooling
[°C]
-10 to 46
-15 to 46
Heating
-15 to 24
Condensate drain line
Material
[-]
PP+LLDPE
-
Diameter (inner / outer)
[°C]
Ø 13.0 /
Ø 16.0 to 16.8
-
