3. Description of the unit
3.1 Technical parameters of condensation units
Model
FG09 / FS09
FG14 / FS14
FG18 / FS18
For refrigerant
Type
R32
R410A
R410A
[g]
600
1250
1250
Model
AOYG09KMTA KAOU14Ui KAOU18Ui
Power supply
[V]
230 V / 50Hz
Permitted power supply range
[V]
198 – 264 V / 50Hz
Max. sup. current
[A]
9.0
12.5
13.5
Fan
Air flow
rate
Cooling
[m
3
/h]
1650
1910
2000
Heating
1450
1740
1910
Type x number
[-]
Axial fan x 1
Motor power input
[W]
23
54
Noise level (pressure)
Cooling
[dB(A)]
46
49
50
Heating
46
49
50
Noise level (power)
Cooling
61
62
62
Heating
62
65
65
Heat exchanger
Dimension
(H x W x D)
[mm]
504 x 650 x 18.2
546 x 876 x 18.2
546 x 842 x 18.2
Fin spacing
1.30
Number of rows x
Number of tubes in one
row
[-] 1 x 24 2 x 26
Tube material
[-]
Copper
Fin material
[-]
Aluminium
Compressor
Type x number
[-]
Rotary x 1
Double rotary x 1
Motor power input
[W]
550
1100
Oil in
Type
[-]
RB74AF
POE
Housing
Material
[-]
Steel sheet
Colour
[-]
Beige
Dimension
(H x W x D)
Net dimensions
[mm]
541 x 663 x 290
578 x 790 x 300
Dimensions including
packaging
602 x 804 x 375
648 x 910 x 380
Weight
Net weight
[kg]
23
40
Weight including
packaging
26
44
Connecting lines
Diameter
Liquid
[mm]
Ø6.35 (ø1/4 in.)
Gas
Ø9.52 (ø3/8 in.)
Ø12.70 (ø1/2 in.)
Without refrigerant
recharge
[m]
15*
Max. length
20
25
Max. height difference
15
Operating range
Cooling
[°C]
-10 to 46
Heating
-15 to 24
Condensate drain line
Material
[-]
PP+LLDPE
-
Diameter (inner / outer)
[°C]
Ø 13.0 / Ø 16.0
to 16.8
-
* For sets with FS units see the DUPLEX R SET manual.
